| Model | UV-2513 | ||
| Printhead | Ricoh Gen 5/Gen 6 Grey Scale Micro Piezo Printhead Quantity:2-8 |
||
| Printing Speed | 8H-All color | High speed Mode | 56.7m²/h |
| Production Mode High Quality Mode |
34.2m²/h 29.2m²/h |
||
| Print Width | 2500mm*1300mm | ||
| Colors | CMYK+Lc+Lm+W+V | ||
| Ink Type | Environment-friendly UV Curing ink | ||
| Ink Supply System | Automatic Negative Pressure Ink Supply System | ||
| RIP Software | Standard: PhotoPrint. Print Factory and Onyx are optional. | ||
| Ink Monitoring System | Voice intelligent Alarm System | ||
| File Format | JPG, TIF, PDF, etc. | ||
| Media Adsorption System | 4 Vacuum Zones, Available for Different Types of Media | ||
| Lifting Function | Carriage Height Automafic Adjustment, Intelligent Detection of Material Thickness | ||
| Working Environment | Temp.:15°C-28°C, Humidity:40%-70% | ||
| Power Supply | 220V 50HZ/60HZ 8.0KW | ||
| Machine size/Weight | 4206*2200*1500mm(L*W*H) 1300kg | ||
| Packaging Size/Weight | 4400*2300*1750mm(L*W*H) 1600kg | ||
