1904-UV Mesh Belt Leather Printer

1904-uv mesh belt leather printer

Mesh belt UV leather printer adopts 1-4 Epson I3200-U1 printhead. UV leather printer supports different printing modes, with CMYK + W + CMYK 3-layer drawing, perfectly presenting brilliant colors. Roll-to-roll machine application, precise guide belt conveying without pressure.

Send Inquiry

Send Email

Wechat:+86 17700639356

Whatsapp:+86 17700639356

Feature Printer Details Specification Video Application Inquiry

Feature

Using CMYK+W+CMYK 3-layer printing, printing picture is more delicate.

Using original UV ink, weak smell , not pungent, and protects the environment.

It is equipped with a leakage protection device, makes printer run more safely.

Three-stage suction control system on platform can ensure smoothness of material adsorption.

High-speed silent ink chain can effectively prolong the working life of mesh belt leather printer.

Roll-to-roll application, precise belt guide and pressure-free transmission to ensure printing effect.

Printer Details

THK Silent Linear Guide

No noise, ensure the stable operation of carriage and ensure the printing quality.

Anti-collision Carriage

Protect printhead during the printing process and reduce maintenance costs.

Liftable Capping Station

Automatic cleaning, automatic flashing and moisturizing function to prevent printhead clogging.

Multiple Print Modes

CMYK+W+CMYK, W+W+CMYK+CMYK, W+CMYK+V, double CMYK mode can be switched to print according to the needs.

Specification

Model	1904-UV
Printhead	1-4 pcs Epson I3200-U1 Printhead
Printing Resolution	3200DPI
Printhead Properties	Automatic cleaning, automatic flashing and moisturizing function
Printing Speed	CMYK CMYK+W+CMYK CMYK+CMYK+W+W Production Mode: 16㎡/h Production Mode: 55㎡/h Production Mode: 38㎡/h High Quality Mode: 10㎡/h High Quality Mode: 32㎡/h High Quality Mode: 23㎡/h CMYK+W+K+W+CMYK CMYK+W+CMYK+V W+CMYK+V Production Mode: 9㎡/h Production Mode: 38㎡/h Production Mode: 14㎡/h High Quality Mode: 5㎡/h High Quality Mode: 23㎡/h High Quality Mode: 8㎡/h
Printing Speed	Printhead Quantity: 1-4
Ink	LED-UV Curing Ink
Ink Color	CMYK+W+V
Printing Width	1900mm
Printhead Cleaning	Automatic Cleaning, Automatic Flash Spray Moisturizing Function
RIP Software	Maintop, FlexiPRINT, Printfactory, etc.
File Format	JPG, TIF, BMP, PDF, etc.
Media	Leather
Transmit Port	Giga-bit Ethernet Port
Applies	Light Film, Transparent Film, PET&PVC, Ultra-transparent Film and Other Decoration Materials
Operation System	Win7 64bit, Win10 64bit Hard Disk: More than 500G, ATI Mobility Radeon, Memory 8G DDR4 above, CD-ROM: DVD ROM, CPU: Intel i7 or above
Power Supply	50/60 HZ, 220V, 16A
Working Environment	Temperature: 20℃-30℃ Humidity: 35％-65％
Machine weight	855KG
Machine size	380013001510mm
